Trading the naked RSI system depicted in this series’s previous video as an overbought/oversold signal generator is too risky, and its long-term results questionable. The system is profitable only in sideways movements. Thus, a trending filter or a detrending step will be needed to avoid the numerous fake signals.

### Divergences and Failure swings

Welles Wilder remarks on two ways to trade the RSI: Divergences and Top/Bottom failure swings.

#### Divergences

A divergence forms when the price makes higher highs (or lower lows), and the RSI makes the opposite move: lower highs (or higher lows). RSI divergences from the oversold area show the market action starts to strengthen, an indication of a potential swing up. In contrast, RSI divergences in the overbought area show weakness and a likely retracement from the current upward movement.

#### Failures

An RSI Top failure occurs with the following sequence of events:

- The RSI forms a pivot high in the overbought area.
- An RSI pullback occurs, and an RSI pivot low forms.
- A new RSI pivot high forms, which is lower than the previous pivot high

Fig 1 – RSI TOP failures in the EURUSD 4H 2H Chart

An RSI Bottom failure occurs with the following sequence of events:

- The RSI forms a pivot low below the oversold area.
- An RSI pullback occurs, and an RSI pivot high forms.
- A new RSI pivot low forms, which is higher than the previous pivot high.

Fig 2 – RSI Bottom failures in the ETHUSD 1H Chart.

According to Welles Wilder, trading the RSI failure swings can be more profitable than trading the RSI overbought-oversold system. Thus, we will test it.

### The RSI Failure algorithm

To create the RSI Failure algorithm, we will need to use the** Finite State Machine** concept, presented in this series’s seventh video.

The Easylanguage code of the RSI system failure is the following:

inputs: Price( Close ), Length(14), OverSold(30), Overbought(70), takeprofit(3), stoploss(1) ; variables: state(0), state1 (0), state2(0), state5 (0), state6(0), rsiValue(0), var0(0), rsi_Pivot_Hi(0), rsiPivotHiFound(False), rsiPivotLoFound (False),rsi_Pivot_Lo(0) ; rsiValue = RSI(C,Length); If rsiValue[1] > rsiValue and rsiValue[1] > rsiValue[2] then begin rsiPivotHiFound = true; rsi_Pivot_Hi= rsiValue[1]; end else rsiPivotHiFound = False; If rsiValue[1] < rsiValue and rsiValue[1] < rsiValue[2] then begin rsiPivotLoFound = true; rsi_Pivot_Lo = rsiValue[1]; end else rsiPivotLoFound = False; If state =0then begin if rsiPivotHiFound = true and rsi_Pivot_Hi> Overbought then state =1{a bearih setup begins} else if rsiPivotLoFound = True and rsi_Pivot_Lo < OverSold then state =5; {a bullish Setup begins} end; {The Bearish setup} If state =1then begin state1 = rsi_Pivot_Hi; if rsiValue > state1 then state =0; if rsiPivotLoFound = true then state =2; end; If state =2then begin state2 = rsi_Pivot_Lo ; if rsiValue > state1 then state =0; if rsiPivotHiFound = true then if rsi_Pivot_Hi<70then state =3; end; If state =3then if rsiValue < state2 then state =4; If state =4then begin sellShort this bar on close; state =0; end; {The bullish setup} If state =5then begin state5 = rsi_Pivot_Lo; if rsiValue < state5 then state =0; if rsiPivotHiFound = true then state =6; end; If state =6then begin state6 = rsi_Pivot_Hi; if rsiValue < state5 then state =0; if rsiPivotLoFound = true then if rsi_Pivot_Lo > OverSold then state =7; end; If state =7then if rsiValue > state6 then state =8; If state =8then begin buy this bar on close; state =0; end; If state >0and rsiValue < OverSold then state =0; If state >0and rsiValue > Overbought then state =0; {The Long position management section} If marketPosition =1and close < entryprice - stoploss* avgTrueRange(10) then sell this bar on close; If marketPosition =1and close < entryPrice + takeprofit* avgTrueRange(10) then sell this bar on close; {The Short position management section} If marketPosition =-1and close > entryprice + stoploss* avgTrueRange(10) then BuyToCover this bar on close; If marketPosition =-1and close < entryPrice - takeprofit* avgTrueRange(10) then BuyToCover this bar on close;

The results, measured on the EURUSD, are not as brilliant as Mr. Welles Wilder stated.

The trade analysis shows that **the RSI Failures system, as is, is a losing system**. This fact is quite common. It takes time to uncover good ideas for a profitable trading system. In the meantime, ** we have developed a practical exercise using the finite state machine concept**, handy for the future development of our own trading ideas.
