Trading the naked RSI system depicted in this series’s previous video as an overbought/oversold signal generator is too risky, and its long-term results questionable. The system is profitable only in sideways movements. Thus, a trending filter or a detrending step will be needed to avoid the numerous fake signals.
Divergences and Failure swings
Welles Wilder remarks on two ways to trade the RSI: Divergences and Top/Bottom failure swings.
Divergences
A divergence forms when the price makes higher highs (or lower lows), and the RSI makes the opposite move: lower highs (or higher lows). RSI divergences from the oversold area show the market action starts to strengthen, an indication of a potential swing up. In contrast, RSI divergences in the overbought area show weakness and a likely retracement from the current upward movement.
Failures
An RSI Top failure occurs with the following sequence of events:
- The RSI forms a pivot high in the overbought area.
- An RSI pullback occurs, and an RSI pivot low forms.
- A new RSI pivot high forms, which is lower than the previous pivot high
Fig 1 – RSI TOP failures in the EURUSD 4H 2H Chart
An RSI Bottom failure occurs with the following sequence of events:
- The RSI forms a pivot low below the oversold area.
- An RSI pullback occurs, and an RSI pivot high forms.
- A new RSI pivot low forms, which is higher than the previous pivot high.
Fig 2 – RSI Bottom failures in the ETHUSD 1H Chart.
According to Welles Wilder, trading the RSI failure swings can be more profitable than trading the RSI overbought-oversold system. Thus, we will test it.
The RSI Failure algorithm
To create the RSI Failure algorithm, we will need to use the Finite State Machine concept, presented in this series’s seventh video.
The Easylanguage code of the RSI system failure is the following:
inputs: Price( Close ), Length( 14 ), OverSold( 30 ), Overbought( 70 ),
takeprofit( 3 ), stoploss( 1 ) ;
variables: state(0), state1 (0), state2(0), state5 (0), state6(0), rsiValue(0),
var0( 0 ), rsi_Pivot_Hi(0), rsiPivotHiFound(False),
rsiPivotLoFound (False),rsi_Pivot_Lo(0) ;
rsiValue = RSI(C,Length);
If rsiValue[1] > rsiValue and rsiValue[1] > rsiValue[2] then
begin
rsiPivotHiFound = true;
rsi_Pivot_Hi= rsiValue[1];
end
else
rsiPivotHiFound = False;
If rsiValue[1] < rsiValue and rsiValue[1] < rsiValue[2] then
begin
rsiPivotLoFound = true;
rsi_Pivot_Lo = rsiValue[1];
end
else
rsiPivotLoFound = False;
If state = 0 then
begin
if rsiPivotHiFound = true and rsi_Pivot_Hi> Overbought then
state = 1 {a bearih setup begins}
else
if rsiPivotLoFound = True and rsi_Pivot_Lo < OverSold then
state = 5; {a bullish Setup begins}
end;
{The Bearish setup}
If state = 1 then
begin
state1 = rsi_Pivot_Hi;
if rsiValue > state1 then state = 0;
if rsiPivotLoFound = true then
state = 2;
end;
If state = 2 then
begin
state2 = rsi_Pivot_Lo ;
if rsiValue > state1 then state = 0;
if rsiPivotHiFound = true then
if rsi_Pivot_Hi< 70 then state = 3;
end;
If state = 3 then
if rsiValue < state2 then state = 4;
If state = 4 then
begin
sellShort this bar on close;
state = 0;
end;
{The bullish setup}
If state = 5 then
begin
state5 = rsi_Pivot_Lo;
if rsiValue < state5 then state = 0;
if rsiPivotHiFound = true then
state = 6;
end;
If state = 6 then
begin
state6 = rsi_Pivot_Hi;
if rsiValue < state5 then state = 0;
if rsiPivotLoFound = true then
if rsi_Pivot_Lo > OverSold then state = 7;
end;
If state = 7 then
if rsiValue > state6 then state = 8;
If state = 8 then
begin
buy this bar on close;
state = 0;
end;
If state > 0 and rsiValue < OverSold then state = 0;
If state > 0 and rsiValue > Overbought then state = 0;
{The Long position management section}
If marketPosition =1 and close < entryprice - stoploss* avgTrueRange(10) then
sell this bar on close;
If marketPosition =1 and close < entryPrice + takeprofit* avgTrueRange(10) then
sell this bar on close;
{The Short position management section}
If marketPosition =-1 and close > entryprice + stoploss* avgTrueRange(10) then
BuyToCover this bar on close;
If marketPosition =-1 and close < entryPrice - takeprofit* avgTrueRange(10) then
BuyToCover this bar on close;
The results, measured on the EURUSD, are not as brilliant as Mr. Welles Wilder stated.
The trade analysis shows that the RSI Failures system, as is, is a losing system. This fact is quite common. It takes time to uncover good ideas for a profitable trading system. In the meantime, we have developed a practical exercise using the finite state machine concept, handy for the future development of our own trading ideas.
